Triangular Flange

Triangular Flange

Our Powder Metallurgy Triangular Flange are manufactured using a precision powder metallurgy process for mechanical assemblies, equipment and custom mounting applications.

The flange features a circular body, a raised central hub, a central bore and four evenly distributed threaded mounting holes. The integrated design provides a compact mounting interface for connecting and positioning components within mechanical assemblies.

Powder metallurgy is well suited to producing this type of flange because it provides efficient material utilization, consistent dimensional quality and repeatable production for medium- and high-volume applications.

Key Features

• Powder metallurgy manufacturing
• Triangular Flange design
• Raised central hub
• Central through bore
• Four threaded mounting holes
• Integrated mounting structure
• Consistent dimensional quality
• Efficient material utilization
• Suitable for high-volume production
• Custom specifications available

Flange Design

The component features a circular flange body with a raised central hub.

A central bore is provided for integration with the mating shaft, sleeve or other mechanical component. Four threaded holes are evenly distributed around the flange to provide secure mounting points.

The circular geometry provides a symmetrical mounting interface and can be adapted to different mechanical assembly requirements.

The bore diameter, hub dimensions, hole pattern, thread specification and overall flange dimensions can be customized according to customer drawings.

Powder Metallurgy Manufacturing

Powder metallurgy provides an efficient manufacturing solution for producing complex mechanical flanges with integrated features.

Key advantages include:

• Near-net-shape production
• High material utilization
• Reduced material waste
• Consistent part-to-part dimensions
• Reduced machining requirements
• Efficient mass production
• Flexible material selection
• Integration of multiple features into one component

Secondary operations such as sizing, machining, tapping, heat treatment and surface finishing can be applied when required.

Applications

Powder metallurgy round mounting flanges can be used in:

• Mechanical assemblies
• Motor and actuator components
• Shaft mounting systems
• Industrial machinery
• Automation equipment
• Power transmission systems
• Pump and machinery components
• Custom mounting assemblies

Custom Manufacturing

We manufacture custom powder metallurgy Triangular Flange according to customer drawings, samples and technical specifications.

Available customization includes:

• Outer diameter
• Overall thickness
• Central bore diameter
• Hub diameter
• Hub height
• Number of mounting holes
• Hole pattern
• Thread specification
• Material grade
• Density
• Heat treatment
• Surface treatment
• Dimensional tolerances

OEM and high-volume production are available.
